In stock
$2,699.00
SKU: CHA-SB35
***For Replacement Parts, contact us***
Description
Materials & Applications
- Structural steel, mild steel, stainless, cast iron, aluminum
- I-beams, H-beams, plate, angle, truck frames, bridgework
- Annular cutting up to 1-1/2″ x 2″, twist drilling to 1″
- Tapping to 3/4″ with reverse
- Reaming and countersinking operations
- Field fabrication, maintenance, MRO, construction installs
Key Advantages
- Auto-Feed Mode: consistent feed rate, extends cutter life, reduces operator fatigue.
- Cycle-Stop Sensor: automatically shuts off once hole is complete, improving safety and productivity.
- Manual Mode: full control when you need it—capacity up to 1-3/8″ diameter × 2″ depth.
- Strong Magnetic Base: 3370 lb holding force ensures secure drilling on vertical/horizontal steel surfaces.
- Reasonable Weight: ~36 lb for easier maneuvering in shop or onsite compared to heavy static rigs.
- 550 RPM Motor: optimized speed for annular cutters in structural steel, stainless, and alloys.
Technical Specifications
- Cutter Capacity (Auto-Feed) 1-3/16″ diameter × 1-3/4″ depth
- Cutter Capacity (Manual Mode) 1-3/8″ diameter × 2″ depth
- Motor Speed 550 RPM (no-load)
- Magnetic Holding Force 3370 lb
- Weight ≈ 36 lb (≈ 16.3 kg)
- Feed Modes Auto-Feed / Manual Feed
