In stock
$2,099.00
SKU: CHA-AC50
***For Replacement Parts, contact us***
Description
Materials & Applications
- Structural/mild steel, alloy steel, stainless, cast iron
- I-beams, H-beams, plate, angle, bridge and building steel
- Annular cutting up to 2-1/8″ diameter × 2″ depth
- Twist drilling up to 1″ with chuck adaptor
- Reaming and countersinking operations
- Field fabrication, shop fabrication, maintenance/MRO, construction installs
Key Advantages
- High-capacity cutter: 2-1/8″ diameter × 2″ depth of cut — perfect for large clearance holes in heavy steel.
- Dual-speed motor with 300/450 RPM options — gives control across materials and applications.
- Solid holding force: 3370 lb magnetic base keeps the unit stable even on vertical or overhead surfaces.
- Relatively lightweight for its class: ~33 lb — easier to handle on site, transport between jobs.
- Quick-change arbor system and compatibility with standard ¾″ Weldon shank annular cutters plus twist drills (up to 1″) for maximum versatility.
Technical Specifications
- Cutter Capacity (Dia × Depth) 2-1/8″ × 2″
- Motor Power 1100 W
- Motor Speed 300 / 450 RPM (2-speed)
- Magnetic Holding Force 3370 lb
- Weight ≈ 33 lb
- Twist Drill Capacity Up to 1″ diameter
